MOBILE IMPACT CRUSHER

MOBILE IMPACT CRUSHER
CAPACITY
100-400 t/h
Max. feed size
600mm
Hybrid power engine
Overall Properties
Raw materials: granite, basalt, limestone, shale, river pebbles, cement clinker, quartz, phosphate rock, bauxite, steel slag, etc.
Applications: primary and secondary crushing applications in mining, aggregates, mineral processing, and recycling construction and demolition waste

The WAF series mobile impact crusher is integrated mobile equipment composed by the feeder, impact crusher, conveyor belts etc.. It uses sophisticated manufacturing technology and selects best quality high chrome plate hammer and wear-resistant liner plate, to make large crushing ratio.

Feature
1. Compact and sturdy chassis enhances the stability of the production process
2. Standard advanced intelligence system
3. Boosted capacity thanks to our Austrian technology AF series impact crushing unit
4. Dual-power package
5. Independent pre-screening unit

Model Max. feed size
(mm)
Capacity
(t/h)
Installed power
(kw)
Generator set
(kw)
Working dimension
(mm)
Delivering dimension
(mm)
WAF270 ≤400 100-200 237.4 300 14550 x 5950 x 4550 12600 x 3300 x 3100
WAF340 ≤500 150-250 287.4 350
WAF380 ≤600 200-300 330.9 400 14550 x 3300 x 3200
WAF430 ≤600 300-400 365.1 450
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
WAF MOBILE IMPACT CRUSHER
