MOBILE CONE CRUSHER

MOBILE CONE CRUSHER
CAPACITY
100-400 t/h
Max. feed size
200mm
Integral crushing & screening
Overall Properties
Raw materials: iron ore, copper, steel slag, slag, river stone, granite, basalt, quartz, diabase, etc.
Applications: secondary medium & fine crusher is widely used in mining, quarry, mixing and batching plant, road and building construction, highway, railway and subway, and water conservancy

The WHPS series mobile cone crusher comprises cone crusher, vibrating screen, belt conveyor, motor and control box and other components. This crushing plant is commonly used in the field of fine crushing operations. In the production of sand and gravel, according to the stone types and different uses of finished products, it can produce gravel products with higher hardness and finer granularity size. The configured cone crusher can be adjusted to different crushing cavity according to the actual needs, which expands the application scope and fields of medium and fine portable cone crusher.

Based on interchangeability and associativity of crushing unit and screening unit, crushing and screening mobile crusher can realize complex processing technology. Whether first crushing and then screening or first screening and then crushing, this machine provides efficiency and convenient operation mode.
WHPS MOBILE CONE CRUSHER
Model Max. feed size
 (mm)
Capacity
(t/h)
Installed power
(kw)
Generator set
(kw)
Working dimension
(mm)
Delivering dimension
(mm)
WHPS200 ≤150 100-200 238 300 16000 x 10500 x 7200 16000 x 3100 x 4000
WHPS300 ≤200 200-400 315 400 18330 x 10400 x 7200 18400 x 3200 x 4000
