WSF
MOBILE SOIL AND STONE SEPARATOR

MOBILE SOIL AND STONE SEPARATOR
Capacity
200-600tph
No water required
Anti-blocking design
Product introduction
The WSF mobile soil and stone separator is generally located at the front end of the process flow, and is especially suitable for separating a large amount of soil contained in the material, and then the bulk material enters the next process for treatment. Generally, two roller screens with different gaps are equipped to separate the mixture into three types: the first is soil or slag, the second is small granular block materials, such as stones and broken bricks, and the third is large materials, such as large stones and concrete blocks. It is also possible to separate only the soil or residue according to the process requirements.

1. Greatly improve the efficiency of debris separation
2. Convey and feed while separating efficiently
3. No water needed to solve the problem of environmental water
4. Complete models can be customized as required
5. Can be used in combination with mobile crushing station
6. Mobile, flexible, convenient and convenient


Model Max. feed size
(mm)
Capacity
(t/h)
Material moisture content
(%)
Installed power
(kw)
Weight
(t)
Drive mode
WSF1616 500 200-400 ≤20 85.5 51 Motor reducer drive
WSF1620 500 400-600 ≤20 123 65 Motor reducer drive
