WLF
MOBILE CRUSHING AND SCREENING PLANT

MOBILE CRUSHING AND SCREENING PLANT
Capacity
100-400 t/h
Max. feed size
600mm
Integrated modular design
Overall Properties
Raw materials:  granite, limestone, basalt, shale, pebbles, ore, steel slag, quartz, silica, gypsum, volcanic rock, marble, river stone, calcite, dolomite, coal gangue, tiles, concrete hollow blocks, cement clinker etc..
Application: minerals and hard rock crushing, construction waste recycling, slag processing, highway and tunnel construction, water conservancy, metallurgy, chemical industry etc.

The WLF series mobile crushing and screening plant is an integration of new type energy-saving, efficient crusher in the international advanced level. Modular design, excellent combination, intelligent wireless operation, low cost and efficient operation. We put the site design, environmental protection, easy to transport, and saving energy as the primary problem to be resolved, providing customers with the best technology of crushing solution.

With high performance, high reliability and attractive appearance, the mobile crushing and screening plant has reached the international advanced level. We can design the primary crushing, secondary crushing, tertiary crushing and combine them according to customers' requirement.

Model Max. feed size
(mm)
Capacity
(t/h)
Installed power
(kw)
Generator set
(kw)
Working dimension
(mm)
Delivering dimension
(mm)
WLF270 ≤400 100-200 255.5 350 19800 x 12000 x 5050 19500 x 3000 x 3800
WLF340 ≤500 150-250 314.1 400 19800 x 12000 x 5050 19500 x 3200 x 3800
WLF380 ≤600 200-300 360.7 450 19800 x 14000 x 6400 19500 x 3200 x 4200
WLF430 ≤600 300-400 395.7 500 19800 x 14000 x 6400 19500 x 3200 x 4200
