BUCKET SAND WASHING MACHINE

XS
BUCKET SAND WASHING MACHINE

Quarry, mining, building materials, chemical industry, water conservancy and hydropower, concrete batching plant
1.
Large capacity, low power consumption
2.
Simple structure, low failure rate
3.
Multiple functions of washing, dewatering and grading
4.
Long service life & no pollution
5.
Digital machining technology, higher precision
Capacity
50-200t/h
Max feeding size
1.2 rpm
Washing, dewatering & grading
Overall Properties
The XS series bucket sand washing machine's biggest characteristic is that the transmission part is separated from water and sand, so failure rate is much lower than other sand washer, and the novel sealing structure and reliable transmission could be well used to ensure the cleaning and dehydration effect.

With features of reasonable structure, large capacity, low power consumption, etc., it is a deserved ideal industrial sand washing equipment. As this XS series bucket sand washing machine is very good for separating and cleaning stone powder and soil in the artificial sand, it is often associated with sand making machine for construction sand crushing and washing.

Model Impeller diameter
(mm)
Impeller width
(mm)
Impeller
quantity
Speed
(rpm)
Power
(kw)
Capacity
(t/h)
Weight
(t)
XS2800 Φ2800 985X2 32 1.2 11 50-100 7.2
XS3200 Φ3200 15 100-150 7.8
XS3600 Φ3600 18.5 150-200 9.3
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
XS BUCKET SAND WASHING MACHINE
