CONSTRUCTION WASTE CRUSHER

DPF
CONSTRUCTION WASTE CRUSHER

Raw material: Construction waste, steel reinforced concrete, brick structure, steel slag and gravel, bluestone, limestone, sandstone screening and so on.
Capacity
20-700t/h
Max feeding size
1000mm
Artificial intelligent system
Overall Properties
The DPF crusher for construction waste is a single-stage crusher, also a domestic dedicated crusher equipped with a rebar shearing device for construction waste.  It crush construction and demolition waste (such as bricks, tiles, waste concrete blocks, etc.) which contain metal materials, cutting the rebar in construction waste like scissors, ensuring that there is almost never happened that host downtime caused by the rotor being wrapped by steel bars. What it "eat" are bricks, concrete blocks and other construction waste, while it can "spit" out the recycled building aggregate alternative to natural gravel.

1. Equipped with rebar-removing device, ensuring the host non-clogging;
2. Simplifying three stages crushing into one stage;
3. Less over-crushed product, and good shape granularity;
4. Semi-opened discharging system, easy maintenance;
5. Low power consumption, saving energy and protecting environment;
6. Simple structure, reliable operation and low operating costs.
Model Max. feed size
(mm)
Product size P80
(mm)
Rotor size
(mm)
Power
(kw)
Capacity
(t/h)
Weight
(t)
DPF15 ≤300 D80≤20 800×650 30 20-35 4
DPF35 ≤400 D80≤20 1000×1030 55 35-60 8.2
DPF65 ≤500 D80≤30 1200×1290 90 60-90 13
DPF90 ≤700 D80≤30 1400×1300 132 90-145 19.1
DPF125 ≤700 D80≤30 1400×1700 160 130-160 24.6
DPF150 ≤850 D80≤30 1600×1560 185 165-220 33.8
DPF180 ≤850 D80≤40 1600×2020 250 210-270 42
DPF250 ≤1000 D80≤40 1800×2000 400 280-450 63
DPF300 ≤1000 D80≤40 2000×2200 560 420-700 96
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
DPF CONSTRUCTION WASTE CRUSHER
