DPX

SINGLE STAGE FINE CRUSHER

Three-in-one crushing technology, turn triple crushing stage into one stage, suitable for cement production, desulfurizing in power plant, mining and metallurgy etc.

Great feeding granularity and high crushing ratio;

Adjustable discharging granularity;

Longer service life of the hammer;

Simple structure lower electricity consumption;

Low management, operating and maintenance cost.

Capacity
15-650t/h

Max feeding size
1300mm

More crushing, less grinding

Overall Properties Technical Specifications PHOTO/VIDEOS CONTACT US

Overall Properties

DSMAC has successfully designed and manufactured DPX series single stage fine crusher on the basis of the single stage hammer crusher. It features large feed granularity and smaller discharging granularity, longer service life, great production capacity, low electricity consumption, convenient maintenance, low operating costs, etc.

Comparing with traditional single stage hammer crusher, the single stage fine crusher has lower product granularity (80% <5mm), and only requires 50~70% equipment investments and can decline 30% long-term operating and management cost.

Model	Rotor size (mm)	Rotor length (mm)	Hammer quantity	Max. feed size (mm)	Inlet size (mm)	Power (kw)	Dimension (mm)	Capacity (t/h)
DPX15III	800	650	12	≤500	570X630	30-37	1615×1662×1636	10-20
DPX35III	1000	1030	24	≤700	1050X760	50-75	2016×2260×2330	10-30
DPX65III	1200	1290	24	≤800	1320X760	90-132	2316×2520×2633	40-60
DPX90III	1400	1300	30	≤900	1330X960	132-200	2654×2871×3060	60-90
DPX125III	1400	1700	35	≤900	1990X960	200-240	2654×3391×3060	80-120
DPX150III	1600	1560	30	≤1100	1520X1120	250-315	3427×3460×3640	100-150
DPX180III	1600	1830	40	≤1100	2050X1200	280-355	3427×3920×3640	100-180
DPX250III	1800	2000	42	≤1300	2180X1320	630	9050×6600×4335	150-250
DPX300III	2000	2200	50	≤1300	2440X1320	800	9650×7200×4735	250-400
