XPCF

HIGH EFFICIENCY FINE CRUSHER

Raw material: Limestone, cement clinker, calcium carbide, coal

Most economic solution to clinker crushing and grinding

High efficiency sand manufacturing application up to 1500 tph throughput rate and 750 tph sand

30 to 50% less power rating

3 to 4 times hammer service life thanks to our SandwichTM hammer

Capacity
10-2000t/h

Max feeding size
500mm

clinker crushing and fine crushing

Overall Properties Technical Specifications PHOTO/VIDEOS CONTACT US

Overall Properties

DSMAC has successfully designed and manufactured the newest XPCF series high efficiency fine crusher. It is mainly used for fine crushing of dinas, sand making, and for crushing in cement factory, etc.

The XPCF series high efficiency fine crusher integrates the rock-on-rock and rock-on-iron principles into one unit. The fed material gets crushed as it enters the crushing cavity and later the crushed portion twists and grinds with each other internally and discharges fines through the grid plate.

Model	Capacity (t/h)	Feed size Max./Eco (mm)	Product size (mm)	Power (kw)	Rotor size (mm)	Single hammer weight (kg)	Weight (t)
XPCF2000	1500-2000	500/200	≤12	2*800	2φ2600×3000	280/52	180
XPCF1500	800-1000	500/200	≤12	800	φ2600×3000	140/52	148
XPCF1000	600-800	350/180		630-710	φ2400×2800	120/52	100.6
XPCF600	400-600	350/180		560-630	φ2200×2600	105/52	82
XPCF400	200-400	350/150		400-450	φ1800×2200	93/52	52
XPCF300	150-300	350/150		315-355	φ1800×1800	69/42	38
XPCF250	150-250	300/150	≤10	220-250	φ1600×1650	45/42	25.1
XPCF200	100-200	300/150	≤10	160-200	φ1600×1350	48/42	21.4
XPCF150	100-150	250/150	≤8	160-200	φ1250×1650	36/42	15.8
XPCF125	80-120			110-132	φ1250×1350	32/42	13.8
XPCF100	50-100			90-110	φ1250×1100	26/42	12.5
XPCF90	60-90	200/100	≤6	90-110	φ1000×1250	34/26	10.5
XPCF80	50-80			75-90	φ1000×1100	30/26	9.6
XPCF70	40-70			55-75	φ1000×950	26/26	9
XPCF60	40-60	150/100	≤5	55-75	φ900×900	20/26	6.4
XPCF50	30-50			45-55	φ900×700	16/26	5
XPCF40	20-40			37-45	φ900×600	14/26	4
XPCF30	20-30	120/70	≤4	37-45	φ800×600	14/26	3.4
XPCF20	10-20	120/70	≤4	30-37	φ800×400	8/26	3
