SAND MAKER (VSI CRUSHER)

PCX
SAND MAKER (VSI CRUSHER)

Last crushing stage in the process for sand manufacturing and products shaping in quarrying and mineral processing industries
1.
Lowest possible cost per ton
2.
Easy to adjust product grading
3.
Premium product shape
4.
Superior for sand manufacturing
Capacity
40-400t/h
Max feeding size
50mm
Last crushing stage
Overall Properties
The PCX series sand maker (VSI crusher) is unique due to its crushing process. Whereas most other types of crusher use metallic parts to crush rock, the VSI crusher uses the rock fed into the machine to crush itself. This autogenously crushing process produces the best-shaped aggregate on the market today.

The PCX series vertical shaft impactor utilizes “stone hitting stone” principle. The feed material goes through the rotor where material gets accelerated and cascaded in to the chamber. Unlike other types of stone hitting iron crushers, the L series crusher offers low cost per ton and the product grading can be adjusted by simply changing the rotate speed of the rotor.
Model Capacity
(t/h)
Max. feed size
(mm)
Rotating speed
(rpm)
Power
(kw)
Dimension
(mm)
Soft rock Hard rock
PCX700 40-90 ≤35 ≤30 1200-2000 55x2 2910×2130×2105
PCX850 80-120 ≤40 ≤35 1200-2000 75x2 4700×2180×2770
PCX1050 120-200 ≤45 ≤40 1000-1700 132x2 4800×2590×3330
PCX1280 160-300 ≤50 ≤45 850-1450 160x2 6000×3050×3070
PCX1400 200-400 ≤50 ≤45 800-1193 (200~220)x2 6208×3397×4030
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
PCX SAND MAKER (VSI CRUSHER)
