DUAL-ROTOR SAND MAKING MACHINE

XPCS
DUAL-ROTOR SAND MAKING MACHINE

Integrating the advantages of hammer crusher, impact crusher and VSI crusher. Adopt the optimized cavity structure to effectively use the cleavage and crushing principle of "stone hitting stone".
1.
Strong shaping effect;
2.
Horizontal rotors arrangement;
3.
Double rotors running oppositely at high speed;
4.
Adaptable to a wide range of feed size.
Capacity
300-1500 t/h
Max feeding size
60mm
“Stone hitting stone” crushing principle
Overall Properties
The XPCS series dual-rotor sand making machine is a new generation of sand making equipment  launched by DSMAC Group after absorbing domestic and foreign technical advantages and based on years of production experience. The XPCS series dual-rotor sand making machine features that it can increase production, reduce power consumption and improve economic benefits effectively. The processing capacity of XPCS series double-rotor sand making machine is up to 1500 tons per hour, and finished machine-made sand can reach 750 tons per hour.

Core Advantages:
1. Integrate the advantages of hammer crusher, impact crusher and VSI crusher;
2. Adopt the optimized cavity structure to effectively use the cleavage and crushing principle of "stone hitting stone";
3. Large production capacity, fine product size, long service life of wear parts;
4. Reduced required motor power, lower power consumption, and convenient maintenance.
5. The particle size ratio can be adjusted according to user requirements.
Model Rotor diameter
(mm)
Rotor width
(mm)
Hammer quantity Max. feed size
(mm)
Product size
(mm)
Power
(kw)
Capacity
(t/h)
Weight
(t)
XPCS300 1200 1800 48 ≤60 ≤545-50% 2×(160-200) 300 45
XPCS500 1400 1900 64 2×(250-280) 500 68
XPCS800 1900 1900 96 2×(400-450) 800 90
XPCS1000 1900 2380 120 2×(500-560) 1000 110
XPCS1600 2300 2600 168 2×(630-710) 1500 145
